Ürün ayrıntıları:
Ödeme & teslimat koşulları:
|
PCB boyutu: | 250mm * herhangi bir uzunluk | pcb kelepçe; ing: | ayarlanabilir basınç pnömatik |
---|---|---|---|
sistem: | Windows 7 | Yazılım: | ar-ge bağımsız olarak |
Görüntüle: | dokunmatik ekran monitör | giriş aygıtı: | klavye fare |
Kamera Sayısı: | 5 | güç: | 380AC 50Hz |
güç tüketimi: | 6kw | montaj modu: | Grup almak cent sopa, cent almak cent sopa |
Bileşenler Alanı: | 0.2mm | besleyiciler istasyonları: | 64PCS |
Nozullar: | 64PCS | Montaj hızı: | 200000CPH |
Montaj yüksekliği: | 13mm |
product details
Producing with 2~4 types of materials with capacity at same time, available for 5m,50m or any length of flexible strip and roll to roll.
Dual-arm four modules with 17 nozzles for each mounting part, and part A/B/C/D can be mounted separately or synchronously.
Calibration automatically, high precision.
Group to take and group to mount.
product Technical parameters of high speed pick and place machine
Model number | HT-F9 |
Dimension | 2700*2120*1550mm |
PCB size | 1200*330~80*330mm |
PCB thickness | 0.5~5mm |
PCB clamping | adjustable pressure pneumatic |
mounting mode | group to take and group to mount |
system | windows 7 |
display | touch screen monitor |
input device | keyboard,mouse |
NO.of camera | 5 sets of imported camera |
mounting precision | ±0.03mm |
mounting height | <13mm |
mounting speed | 200000CPH |
components | LED3014/3020/3528/5050 and resistors, capacitors, bridge rectifiers |
components space | 0.2mm |
NO.of feedings station | 68pcs |
NO.of nozzles | 68pcs |
power | 380AC 50HZ |
power consumption | 6KW |
operating environment | 23℃±3℃ |
conveyor transmission | MAX length:1200mm |
transmission speed | >500mm/sec |
transmission direction | single(left→right,right→left) |
transmission mode | online drive |
position mode | optical |
air pressure | >5.0kg/c㎡ |
electrical control | independent research and development by ETON |
motion control card module 1set | independent research and development by ETON |
X.Y axis drive way | high-end magnetic linear motor+servo motor |
feeding way | electric feeder with double motor |
Business terms of smt mounter
Accepted delivery terms | EXW, FOB, CIF, CFR |
Accepted payment currency | USD,CNY |
Accepted payment type | L/C, T/T |
Nearest port | Shenzhen |
product parts of smt mounter
Packing & delivery of smt mounter machine
